Woodpecker Mini Ray Portable X-Ray Machine

Woodpecker Mini Ray Portable X-Ray Machine

The Woodpecker Mini Ray Portable X-Ray Machine is an advanced, high-frequency DC X-ray imaging device designed to deliver optimal safety, efficiency, and precision. It is engineered to meet the highest international standards, ensuring minimal radiation leakage and superior image quality. The device is shielded with 99.9% pure lead in the oil tank and beam limiter, guaranteeing exceptional radiation protection and operator safety.

This X-ray machine is equipped with a 50k tube wattage and a 2mA tube current, providing precise exposures and a powerful 140W output power for various clinical applications. With its integrated “CHIP” technology, the Mini Ray maintains stable X-ray output even when battery levels fluctuate, ensuring consistent image quality throughout its use.

Powered by a long-lasting 1800ml x 35 lithium battery, the device can take up to 506 shots on a full charge and features a rapid 2-hour full recharge time. The USA angle sensor offers real-time display and accurate shooting angle calibration based on patient posture, making it ideal for achieving high-precision X-ray images.

The Woodpecker Mini Ray boasts a compact and lightweight design, making it easy to operate with one hand. Its 2.8-inch HD digital screen and user-friendly interface, coupled with ultra-sensitive buttons, provide an intuitive and seamless experience for the operator. With multiple safety measures, including fast screen lock, high-pressure and high-temperature protection, and automatic exposure cancellation, this X-ray machine ensures the highest levels of protection for both patients and operators.

Key Features

Radiation Protection:

• • Complies with international safety standards.
  • Radiation leakage ≤ 0.05mGy/h (CE safety standard).
  • 99.9% pure lead shielding in the oil tank and beam limiter.

Efficient Shooting:

• • 50k tube wattage enhances penetration.
  • 2mA tube current ensures precise exposures.
  • 140W output power supports diverse clinical applications.

Advanced “CHIP” Technology:

• • Stabilizes X-ray output for consistent imaging.
  • Mitigates low battery impact on image quality.

Long-Lasting Battery:

• • High-capacity 1800ml x 35 lithium battery supports up to 506 shots on a full charge.
  • Quick 2-hour full recharge time for enhanced productivity.

Accurate Imaging Sensor:

• • USA angle sensor for real-time display and shooting angle calibration based on posture.

Durable Build:

• • High-frequency X-ray tube designed for 60,000+ exposure cycles, ensuring extended service life.

Focused Imaging:

• • 0.4mm focal spot delivers clear, high-resolution images for precise diagnostics.

User-Friendly Design:

• • 2.8″ HD digital screen with an intuitive interface and ultra-sensitive buttons for easy operation.
  • Compact and lightweight, enabling one-hand operation.

Adaptable to Diverse Needs:

• • Two target groups: Child/Adult.
  • Three device options: Sensor/Scanner/Film.
  • Five tooth position options for versatile usage.

Upgraded Safety Measures:

• • Fast screen lock prevents accidental touches.
  • High-pressure and high-temperature protection safeguards the device and operator.
  • Automatic exposure command cancellation for added safety.

Clinical Benefits

• Provides high-quality radiographs with excellent clarity for accurate diagnosis.
• Reduces radiation exposure to patients with non-invasive diagnostic imaging.
• Compatible with IOPA film and RVG systems, ensuring ease of use and adaptability.

Technical Specifications :-

• Tube Voltage: 70kV
• Tube Current: 2mA
• Battery Capacity: 2500mAh 3S
• DC High Frequency: Consistent performance and output
• Dimensions: 338mm x 112mm x 247mm
• Weight: 2.2 kg
• Output Radiation Field: Φ6cm ± 0.6cm

Environmental Conditions:

• • Operating Temperature: 10°C ~ 40°C
  • Relative Humidity: 30% ~ 75%
  • Atmospheric Pressure: 70kPa ~ 106kPa

Storage & Transportation Conditions:

• • Storage Temperature: -20°C ~ 55°C
  • Transportation Temperature: -20°C ~ 55°C
  • Relative Humidity: 10% ~ 93%
  • Atmospheric Pressure: 70kPa ~ 106kPa

Packaging :-

• 1 x Mini Ray Portable X-Ray Machine
• 1 x Power Adapter & Cable
• 1 x User Manual

The Woodpecker Mini Ray Portable X-Ray Machine is a top-tier choice for dental professionals seeking superior imaging performance, enhanced safety, and reliable operation in a compact and portable form. With its robust build, high-quality imaging capabilities, and user-friendly design, this device is ideal for a wide range of dental imaging needs.
